ESP32 S3 development board with 4.3-inch 5-inch IPS HD IPS resistive touch screen Arduino programming development LVGL

ESP32 S3 development board with 4.3-inch 5-inch IPS HD IPS resistive touch screen Arduino programming development LVGL
ESP32 S3 development board with 4.3-inch 5-inch IPS HD IPS resistive touch screen Arduino programming development LVGL - Image 2
ESP32 S3 development board with 4.3-inch 5-inch IPS HD IPS resistive touch screen Arduino programming development LVGL - Image 3
ESP32 S3 development board with 4.3-inch 5-inch IPS HD IPS resistive touch screen Arduino programming development LVGL - Image 4
ESP32 S3 development board with 4.3-inch 5-inch IPS HD IPS resistive touch screen Arduino programming development LVGL - Image 5

Rp669.999

SKU: TP-88799144 Category:

Description

4.3” LCD-TFT HMI Capacitive touch or Resistance touch display module

Supports WiFi and Bluetooth

Support lithium battery power supply

Capacitive touch or Resistance touch

480 x 272 screen resolution

RGB 65K true-to-life colours

Onboard 240MHz LX6 MCU

520K Byte RAM

8 MB PSRAM

4 MB Flash memory

JST1.25 4 Pins (+5V, TX, RX, GND) TTL serial interface
